LED controllers
Our LED controllers enable precise control of different light colours, brightness levels and lighting zones.
Depending on the lighting system used, warm white, RGB, RGBWW or other multi-channel lights can be controlled individually and combined to create coordinated lighting scenes.
Precise control for various LED systems
DALI 1-channel controller
The DALI 1-channel controller enables the reliable control of single-colour constant-voltage LED systems via a DALI bus. The DALI address is automatically assigned by the DALI master, whilst the pre-set logarithmic dimming curve enables smooth brightness control from 0 to 100 per cent.
- DALI DT6 with one channel
- For constant-voltage LED systems
- Input voltage from 12 to 48 V DC
- Automatic assignment of the DALI address
- Logarithmic PWM dimming from 0 to 100 per cent
DALI 4-Kanal Controller
The DALI 4-channel controller allows up to four constant-voltage LED channels to be controlled separately. This makes it suitable for both multiple single-colour lighting circuits and multi-channel lighting systems. The required DALI addresses can be assigned automatically by the DALI master or manually via the integrated display.
- DALI DT6 with four channels
- Four individually controllable outputs
- Input voltage from 12 to 48 V DC
- Up to 5 A output current per channel
- Logarithmic dimming range from 0 to 100 per cent
